OM3 MPO Patch Cord 12 Core Aqua Fiber Optic Connector For Efficient Networking
Product Details:
| Place of Origin: | China |
| Brand Name: | Color Optic |
| Model Number: | CO-1X1CP |
|
Detail Information |
|||
| Fiber Mode: | OM3 | Fiber Grade: | G652D |
|---|---|---|---|
| Core Count: | 12 | Return Loss: | ≥20dB |
| Cable Type: | Patch Cord | Storage Temperature: | -40℃~85℃ |
| Durability: | ≥1000 Times | Connector Polishing: | PC |
| Highlight: | MPO Patch Cord 12 Core,OM3 MPO Patch Cord,OM3 Networking Patch Cord |
||
Product Description
12 Core MPO Patch Cord Aqua Fiber Optic Connector for Efficient Networking
Product Description:
MPO Patch Cord is a kind of high-speed and high-capacity interconnect solution, which uses 12-fiber MPO connector with PC polishing. It offers a Return Loss of more than 20dB, making it an ideal choice for data centers and other applications. The patch cords are built with G652D single-mode fiber, which offers excellent temperature stability from -20℃ to 70℃. The jacket of the MPO Patch Cord is made of a special material, which provides excellent protection against harsh environment and ensures maximum durability. In addition, the low Insertion Loss makes it ideal for long-distance connections. The color of the patch cord is Aqua.
Features:
- Product Name: MPO Patch Cord
- Fiber Grade: G652D
- Fiber Mode: OM3
- Fiber Count: 8/12/24/36/48/72fibers
- Return Loss: PC≤-35dB, APC≤-60dB
- Operating Temperature: -20℃~70℃
- Storage Temperature: -40℃~85℃
- Durability: ≥1000 Times
- Jacket Material: OFNP/LSZH
Technical Parameters:
| Parameter | Specification |
|---|---|
| Cable Length | 1m |
| Connector Polishing | PC |
| Color | Aqua |
| Insertion Loss | ≤0.2dB |
| Return Loss | ≥50dB |
| Operating Temperature | -20℃~70℃ |
| Cable Type | Patch Cord |
| Fiber Mode | OM3 |
| Jacket Material | PVC |
| Durability | ≥1000 Times |
| Connector Type | MPO |
Applications:
Customization:
Brand Name: Color Optic
Model Number: CO-1X1CP
Place of Origin: China
Cable Type: Patch Cord
Fiber Grade: G652D
Storage Temperature: -40℃~85℃
Connector Polishing: PC
Connector Type: MPO
The MPO patch cord has high Return Loss performance and is designed with Multi-fiber Push On (MPO) connectors for quick, easy and reliable connections.
We offer a range of MPO patch cords in lengths from 0.5m to 10m, and can customize lengths and styles to meet your specific needs.
Packing and Shipping:
Packaging and Shipping for MPO Patch Cord:
- The patch cords are individually packaged in antistatic bags, then placed into cardboards.
- The cardboards are then placed into cartons.
- The cartons are then shipped by air or by sea as per customer's request.
