100G QSFP28 BiDi ER1 Single Fiber SFP Optical Module Transceiver For SMF Transmission
Product Details:
| Place of Origin: | China |
| Brand Name: | coloroptic |
| Certification: | UL, TUV, CE, RoHS, REACH, CMRT |
| Model Number: | C-Q81H13EB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plates with Carton |
| Delivery Time: | 7~15 days |
| Payment Terms: | TT, LC, Western Union |
| Supply Ability: | 5000 pieces/month |
|
Detail Information |
|||
| Data Rate: | 100G | Wavelength: | Single Lamda |
|---|---|---|---|
| Distance: | 40 Km | Connector: | Single Fiber LC |
| Form Factor: | QSFP28 | Temperature: | 0~70°C |
| DDM: | Yes | Protocals: | MSA |
| Warranty: | 3 Years | Label: | Can Be Customized |
| Protocols:: | To IEEE 802.3ba 100GBASE-ER1 BIDI | Application: | 100GBASE-ER1 Ethernet Links |
| Highlight: | BiDi SFP Optical Module,QSFP28 SFP Optical Module,100G Single Fiber SFP Transceiver |
||
Product Description
100G QSFP28 BiDi ER1 Single-Fiber Optical Transceiver Module For 40km SMF Transmission
100G QSFP28 BiDi ER1 single-fiber optical transceiver module is designed for 100G Ethernet links over 40km of single-mode fiber transmission. The module contains a single channel of optical signaling and operates at 100Gbps data rate. The module can convert four 25Gbps (NRZ) electrical signals to one 100Gbps (PAM4) optical signal or one 100Gbps (PAM4) optical signal to four 25Gbps (NRZ) electrical signals. The module’s electrical interface complies with OIF CEI-28G-VSR and QSFP28 MSA.
Key Features
- Supports 100GBASE-ER1-40 BIDI
- Lane signaling rate 106.25Gb/s with PAM4,
- Up to 40km transmission on SMF
- EML Laser and APD receiver
- 4x25.78Gb/s with NRZ electrical interface (CAUI-4)
- High speed I/O electrical interface
- I2C interface with integrated Digital Diagnostic monitoring
- QSFP28 MSA package with simplex LC connector
- Single +3.3V power supply
- Support HW TX_DIS and RX_LOS for telecom application
- Maximum power consumption 4.5 W
- Operating case temperature: 0 to +70 °C
- Compliant to 802.3cu, SFF-8636&SFF-8679 standard
- Complies with EU Directive 2015/863/EU
Application
· Wireless application
· 100G Ethernet
· Enterprise networking
Product Detail
It is uniquely serialized and data-traffic and application tested to ensure that they will integrate into your network seamlessly. Digital optical monitoring (DOM) support is also present to allow access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.
Outline Dimensions:
