Duplex LC SMF SFP Optical Module Cisco QSFP-100G-LR4-S Compatible 100GBase-LR4 QSFP28
Product Details:
| Place of Origin: | China |
| Brand Name: | Color Optic |
| Certification: | ROHS |
| Model Number: | CO-S81H13LC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | 5 DAYS |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000 pieces/month |
|
Detail Information |
|||
| Application: | Ethernet/ OTU4 | Distance: | 10km |
|---|---|---|---|
| Voltage Supply: | 3.3V | Data Rate: | 100G |
| Receiver Type: | APD | Fiber Type: | SMF |
| Connector Type: | LC | Product Name: | QSFP28 Optical Module |
| Highlight: | Duplex LC SFP Optical Module,SMF SFP Optical Module,Cisco QSFP-100G-LR4-S |
||
Product Description
Cisco QSFP-100G-LR4-S Compatible 100GBase-LR4 QSFP28 1310nm 10km DOM Duplex LC SMF Optical Transceiver Module
Product Description:
The CO-S81H13LC is a 103/112 Gbps transceiver module designed for optical communication applications compliant to 100GBASE-LR4 of the IEEE P802.3ba standard and OUT-4. The module converts 4 input channels of 25/28 Gbps electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 103/112 Gbps optical transmission. Reversely on the receiver side, the module de-multiplexes a 103/112 Gbps optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data. The central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm as members of the LAN WDM wavelength grid defined in IEEE 802.3ba. The high-performance cooled LAN WDM EA-DFB transmitters and high sensitivity PIN receivers provide superior performance for 100G applications up to 10km links and compliant to optical interface with IEEE802.3ba Clause 88 100GBASE-LR4 and OUT-4l1-9D1F requirements. The product is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP+ Multi-Source Agreement (MSA).
ColorOptic's CO-S81H13LC is a Cisco® compatible 100GBase QSFP28 Optical Transceiver and is factory pre-programmed with all the necessary configuration data for seamless network integration. Our transceivers perform identically to QSFP Cisco® original transceivers and are 100% compatible with other OEM and third party transceivers. The CO-S81H13LC Cisco 100G optical transceiver is 100% MSA (Multi-Source Agreement) compliant. All of ColorOptic's QSFP28 Cisco compatible transceivers are tested for 100% functionality and guaranteed compatible for outstanding network performance.
Features:
- Specifications compliant with SFF-8636
- Up to 103.125Gbps Data Links
- Up to 10km transmission on SMF
- Transmitter: cooled 4x25Gb/s laser
- Receiver: 4x25Gb/s PIN receiver
- Case operating temperature: Commercial: 0℃ to +70℃
- Single +3.3V power supply
- Power Consumption<4.0W
- RoHS compliant
Technical Parameters:
| Form Factor: | QSFP28 |
| TX Wavelength: | 1310nm |
| Reach: | 10km |
| Cable Type | SMF |
| Rate Category: | 100GBase |
| Interface Type: | LR4 |
| DDM: | Yes |
| Connector Type: | Dual LC |
| Optical Power Budget: | 7.3dB |
| TX Power Min/Max | -1.3 to 4.5 dBm |
| RX Power Min/Max | -8.6 to 4.5 dBm |
Applications:
- 100GBASE-LR4
- Infiniband QDR and DDR interconnects
- Client-side 100G Telecom connections
Packing and Shipping:
We package and ship SFP Optical Modules with the following guidelines:
- Each unit is packaged in its original box.
- The box is sealed and labeled with product information.
- The box is then placed inside a larger box for additional protection.
- The larger box is sealed and labeled with product information.
- The box is then sent via a reputable mail courier with tracking information.
FAQ:
- Q: What is the Brand Name of this SFP Optical Module?
- A: The Brand Name of this SFP Optical Module is Color Optic.
