Fiber Channel Transceivers 8G SFP28 SR OM4 For 100M Optimal Networking
Product Details:
| Place of Origin: | China |
| Brand Name: | Color Optic |
| Certification: | ROHS |
| Model Number: | CO-SP0885SC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50 |
|---|---|
| Packaging Details: | Carton |
| Delivery Time: | 5-8 DAYS |
| Payment Terms: | L/C, T/T |
|
Detail Information |
|||
| Cable Type: | MMF | Data Rate: | 8G |
|---|---|---|---|
| Connector: | LC | Product Type: | Fiber Channel Transceivers |
| Application: | Tri-Rate / Fibre Channel | Distance: | 100m |
| Warranty: | 3 Years | Package: | Standard/Customized |
| Highlight: | 8G Fiber Channel Transceivers,Fiber Channel Transceivers OM4,SFP28 Networking Transceiver |
||
Product Description
Fiber Channel Transceivers 8G SFP28 SR OM4 for 100M Optimal Networking
Product Description:
Fiber Channel Transceivers 8G SFP+ transceivers are high performance, cost effective modules supporting data rate of 8.5Gbps. The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
Features:
- Compliant to FC-PI-5 (8GFC )
- Up to 28.05Gb/s data links
- 850nm VCSEL transmitter
- PIN photo-detector
- 2-wire interface for management specifications compliant with SFF-8472 digital diagnostic monitoring interface for optical transceivers
- Operating case temperature: 0 to 70°C
- All-metal housing for superior EMI performance
- Electrical interface compliant to FC-PI-5 8GFC
- Maximum power consumption 1.0W
- Advanced firmware allow customer system encryption information to be stored in transceiver
- RoHS compliant
Technical Parameters:
| Part No. | CO-SP0885SC | Form Factor | SFP+ |
| Data Rate | 8.25G/ps | Distance | 300M |
| Wavelength | 850nm | Operation Temperature | 0 to 70°C (32 to 158°F) |
| Connector | Duplex LC | Voltage | 3.3V |
| Cable Type | MMF | DDM | Yes |
| Transmitter Type | VCSEL 850nm | Receiver Type | PIN |
| TX Power | -6.5~-0.5dBm | Receiver Sensitivity | < -10.5dBm |
| Protocols | MSA Compliant | Warranty | 3 years |
Applications:
The Color Optic CO-S885LC Fiber Channel Transceiver is a high performance, cost effective solution designed for Tri-Rate / Fibre Channel applications. It meets the needs of data centers and enterprise networks, providing customers with a reliable and secure connection. The product is manufactured with the highest quality standards and is backed by a 3-year warranty from the manufacturer.
