High Speed 40Gbps Data Rate Infiniband Pcie Card With XLPPI Interface
Product Details:
| Place of Origin: | China |
| Brand Name: | Color Optic |
| Certification: | ROHS |
| Model Number: | CO-4002E |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50 |
|---|---|
| Price: | USD |
| Packaging Details: | Carton |
| Delivery Time: | 5-8 DAYS |
| Payment Terms: | Western Union, T/T, L/C |
| Supply Ability: | 5000 pieces/month |
|
Detail Information |
|||
| Interface Standard: | PCI-Express 3.0 | PCI Express Voltage: | +12V ±8% |
|---|---|---|---|
| Warranty: | 3 Years | Certifications: | CE, FCC, RoHS |
| Storage Temperature: | -20-70°C | Operating System: | Linix/ Windows |
| Humidity: | 5%-95% | Product Name: | Infiniband Pcie Card |
| Highlight: | XLPPI Interface Infiniband Pcie Card,40Gbps Infiniband Pcie Card |
||
Product Description
Infiniband Pcie Card with XLPPI Interface High-Speed 40Gbps Data Rate
Product Description:
CO-4002E is a PCI Express X8 dual-port 40GQSFP + Ethernet network adapter developed independently by GRT based on the Intel XL710-BM2 master scheme. At the same time it can be compatible with PCIe X8, PCIe x16 channels.
The company's products have passed FCC, CE, ROHS and other international authoritative certification and national industry certification.
Technical Parameters:
| 40Gigabit QSFP+Ethernet Network Adapter CO-4002E | |
| QSFP+ (Quad Small Form factor Pluggable) support |
XLPPI interface supports 40GBase-R PCS and 40Gigabit PMA in order to connect with the QSFP+ 40Gbase-SR4/40Gbase-LR4/4G Direct Attach Cable |
| IEEE Standard/Network Topology: | 40Gigabit Fiber Optic Ethernet, 40Gbase-SR4(850nm LAN PHY) |
| 40Gigabit Fiber Optic Ethernet, 40Gbase-LR4(1310nm LAN PHY) | |
| Operating System Support | |
| Operating System | Windows |
| Linux | |
| General Technical Specifications | |
| Interface Standard |
PCI-Express 3.0specification(8GT/s) |
| Board Size | 165mm X 69mm(6.496" X 2.717") |
| PCB board thickness: 0.062" | |
| PCI Express Voltage | +12V ±8% |
| Bus type | PCI Express X8 Lane |
| Controller | Intel FTXL710-BM2 |
| Bracket | Metal |
| Weight | 170g (5.997 oz) |
| Power Consumption | 2.880 W |
| Storage Humidity | 0%–90%, non-condensing |
| Operating Temperature | 0°C – 45°C (32°F – 113°F) |
| Storage | -40°C–65°C (-40°F–149°F) |
| EMC Certification | FCC PART 15B |
| EN 55022: 2010 | |
| EN 55024: 2010 | |
| EN 61000-3-2:2014 | |
| EN 61000-3-3:2013 | |
| LEDs | |
| LED: | Green light=10Gb linked |
| Yellow light =40Gb linked: Yellow Light | |
| Blu=Activity | |
| Connector | QSFP+ cap: MOLEX, P/N 75586-0010 or compatible |
Support and Services:
At Infiniband Pcie Card, we strive to provide our customers with the highest quality products and services. Our technical support and service teams are here to help you with any issue you may have.
We offer a range of technical support services for our Infiniband Pcie Card products. Our technical support team is available to answer any questions you may have about our products or services. We offer support via phone, email, and live chat. We also offer online tutorials, FAQs, and troubleshooting guides to help you quickly and easily resolve any issues.
We offer a one-year limited warranty on all of our Infiniband Pcie Card products. This warranty covers any defect or malfunction in the product for up to one year from the date of purchase. If you experience any issues with your product, please contact our customer service team for assistance.
If your Infiniband Pcie Card product experiences a malfunction or defect within the one-year warranty period, we will repair or replace the product free of charge. If your product is damaged due to misuse or improper care, we may still be able to offer a repair or replacement service at a discounted rate. Please contact our customer service team for more information.
FAQ:
- Q1: What is an Infiniband PCIe Card?
- A: An Infiniband PCIe Card is a high-performance, low-latency interconnect technology that enables multiple computers to communicate directly with each other over a PCIe (Peripheral Component Interconnect Express) bus.
- Q2: What is the Brand Name and Model Number of Infiniband PCIe Card?
- A: The Brand Name is Color Optic and the Model Number is CO-.
- Q3: Where is the Infiniband PCIe Card made?
- A: The Infiniband PCIe Card is made in China.
- Q4: What are the benefits of using an Infiniband PCIe Card?
- A: Infiniband PCIe Card provides high-speed, low-latency data transfer between multiple computers, and offers reliable, high-performance connections over long distances.
- Q5: Does Infiniband PCIe Card support hot swap?
- A: Yes, Infiniband PCIe Card supports hot swap technology for easy installation and removal of the card.
