Mellanox QDD-400G-SR8 QSFP-DD MPO MMF Optic Transceiver Module 850nm 100m
Product Details:
| Place of Origin: | China |
| Brand Name: | ColorOptic |
| Certification: | ROHS, CE |
| Model Number: | CO-QD4H85S8C |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Seal trays and cartons |
| Delivery Time: | 5 DAYS |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 pieces/month |
|
Detail Information |
|||
| Distance: | 100m | Type Of Media: | MMF |
|---|---|---|---|
| Warranty: | 3 Years | Wavelength (nm): | 850nm |
| Data Rate: | 400G | Technology: | Parallel Optics |
| Fiber Connector: | MPO-12 | Label: | Can Be Customized |
| Highlight: | QDD-400G-SR8 Optic Transceiver Module,QSFP-DD Optic Transceiver Module |
||
Product Description
Mellanox 400G QSFP-DD SR8 Compatible 400GBase-SR8 QSFP-DD 850nm 100m DOM MPO MMF Optical Transceiver Module
Product Description:
The 400G QSFP-DD SR8 is a 400G QSFP-DD SR8 pluggable transceiver. Each channel operates with PAM4 modulation scheme at 26.5625G baud rate, and up to 100m using OM3 fiber.
An optical fiber cable with an MTP/MPO-12 connector can be plugged into the module receptacle. Proper alignment is ensured by the guide pins inside the receptacle. The cable usually cannot be twisted for proper channel to channel alignment. Electrical connection is achieved through a QSFP-DD MSA-compliant edge type connector.
The product is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP-DD Multi-Source Agreement (MSA) Type 2. It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.
Features:
- QSFP-DD MSA compliant
- Electrical interface compliant with 400GAUI-8 and CEI-56G-VSR-PAM4
- Bi-directional operation: 8 x Tx, and 8 x Rx at 53.125Gb/s with 26.5625G PAM4 modulation scheme
- Built in DSP
- Enabled by 850nm VCSEL
- Operating case temperature 0°C – 70°C
- Hot pluggable
- Power consumption 9.5W per end
- Transmission distance up to 100m with OM3 fiber
- Laser eye safety Class 1
- CMIS management interface
Technical Parameters:
- Data Rate: 400G (8x50Gb/s)
- Supply voltage: 3.3V
- Power consumption: 9.5W (digital), 7W (analog)
- Temp: 0°C – 70°C
- Reach: 100m with OM3 fiber
Applications:
- 400Gb Ethernet interconnect
- Switch to switch connectivity
- High performance computing
